Dây rút Panduit 203mm x 4.7mm Natural [BT2S-M]

Name: Dây rút Panduit 203mm x 4.7mm Natural [BT2S-M]
Brand: Panduit
SKU: PAA065
Price: 2000.0 VND
Availability: InStock

Mã kho: PAA065

Mã nhà sản xuất: BT2S-M

Tên nhà sản xuất: Panduit

2.000₫ - 2.000₫

2.000₫

2.000₫ - 2.000₫

2.000₫

📩 Liên hệ để có giá tốt: CV@chanhvinh.com

Wire Routing, Management & Protection / Cable Wire Ties Mounts Straps / : Panduit BT2S-M

MÔ TẢ SẢN PHẨM

The BT2S-M Dome-Top® barb ty, features a unique patented design with its round smooth edges. Paired with the stainless-steel locking barb, these cable ties provide consistent performance, reliability and infinite adjustability through the entire bundle range. Standard cross section, 8.0” (203mm) length. Appropriate for Indoor use, made of Nylon 6.6, are natural in color and come in packages of 1000.

_THÔNG SỐ KỸ THUẬT:

Product Type	Cable Ties
Color	Natural
Environment	Indoor
Sub Brand	Dome-Top®
For Use With	GTS-E, GS2B-E, GTH-E, GS4H-E, STS2, STH2, PTS, PTH
Material	Nylon 6.6
Resistance Properties	NA
Maximum Bundle Diameter (In.)	2
Maximum Bundle Diameter (mm)	51
Maximum Installation Temperature (°C)	0
Maximum Installation Temperature (°F)	32
Maximum Operating Temperature (°C)	85
Maximum Operating Temperature (°F)	185
Minimum Bundle Diameter (In.)	0.06
Minimum Bundle Diameter (mm)	1.5
Minimum Installation Temperature (°C)	-20
Minimum Installation Temperature (°F)	-4
Minimum Loop Tensile Strength (N)	222
Minimum Loop Tensile Strength (lb)	50
Minimum Operating Temperature (°C)	-60
Minimum Operating Temperature (°F)	-76
Overall Length (In.)	8
Overall Length (mm)	203
Body Width (In.)	0.185
Body Width (mm)	4.7
Body Thickness (In.)	0.045
Body Thickness (mm)	1.2
Standards Met	UL 62275 (File E56854), CSA-C22.2 No. 62275, 11130200, NRC 10CFR50, QPL-AS23190, CSA Certified, RoHS Complaint
Military Cross Reference Number	MS3367-1-9
