Panduit Wire Termination, [CD-920-750]; PAI494

Mã kho: PAI494
Mã nhà sản xuất: CD-920-750
Tên nhà sản xuất: Panduit
Original price 6.763.950₫ - Original price 6.763.950₫
Original price
6.763.950₫
6.763.950₫ - 6.763.950₫
Current price 6.763.950₫
📩 Liên hệ để có giá tốt: CV@chanhvinh.com

Wire Termination / Crimpers Cutters Strippers Accessories / Crimping Tools, Pumps & Accessories: Panduit CD-920-750

MÔ TẢ SẢN PHẨM

The CD-920-750 provides circumferential crimp results in terminations with premium electrical and mechanical performance with Panduit copper compression lugs and splices. Crimping dies and connectors are color-coded for easy matching while the part number is permanently marked on the crimping die fo

_THÔNG SỐ KỸ THUẬT:

Metric Class 2r Conductor Size for Copper Lugs, Splices(mm²) 400
Aluminum Conductor Size (kcmil) 600
Copper Conductor Size (kcmil) 750
Panduit Die Index Number P106
Color Code Black
Flex Conductor Size (kcmil) 646
For Use With Crimp die for use with Panduit CT-920, CT-2920, CT-930, CT-2930/L, CT-2930/LE, CT-2931 and CT-2931/E crimp tools and CT-930/CH crimp head, can also be used with Panduit CT-2940/L and CT-2940/LE crimp tools and CT-940CH crimp head with CD-940-DA die adapter sold separately.
Connection Type Crimp
Sub Brand Pan-Lug™
Application Crimp dies for Panduit Power Connectors and Splices.
Crimp Profile Circumferential
Base Material Steel
Finish/Coating Black Oxide
Product Type CD-920 Crimp Dies
Part Features Color coded to connector,premium crimp,embosses die number
