The closed cable tie connector ring in black is made of heat-stabilized nylon 6.6, which increases mechanical strength, heat and wear resistance, and stiffness. It is 0.57" long x 0.36" wide (14.5 x 9.1 mm) and is used with miniature, intermediate, standa

Mã kho: PAK558
Tên nhà sản xuất: Panduit
Original price 7.570₫ - Original price 7.570₫
Original price
7.570₫
7.570₫ - 7.570₫
Current price 7.570₫
📩 Liên hệ để có giá tốt: CV@chanhvinh.com

Wire Routing Management Protection / Cable Wire Ties Mounts Straps / Cable Tie Accessories: Panduit CR4H-M30

MÔ TẢ SẢN PHẨM

Panduit CR4H-M30 Closed Cable Tie Connector Ring Mounts connect multiple wire bundles or hang bundles from conduit, eliminating the need for saddle clamps. These mounts can be used with miniature, intermediate, standard, heavy-standard and light-heavy cable ties and are intended for outdoor environm

_THÔNG SỐ KỸ THUẬT:

Application Connect Multiple Cable Bundles
Product Type Connector Ring
Color Black
Environment Indoor
For Use With Cable Ties : M, I, S, HS, LH
Material Heat Stabilized Nylon 6.6
Maximum Installation Temperature (°C) 115
Minimum Installation Temperature (°C) -20
Maximum Installation Temperature (°F) 239
Minimum Installation Temperature (°F) -4
Maximum Operating Temperature (°C) 115
Minimum Operating Temperature (°C) -60
Maximum Operating Temperature (°F) 239
Minimum Operating Temperature (°F) -76
Overall Height (In.) 0.3
Overall Height (mm) 7.6
Overall Length (In.) 0.57
Overall Length (mm) 14.6
Overall Width (In.) 0.36
Overall Width (mm) 9.1
Resistance Properties Heat Resistant
Standards Met UL Recognized #E136577
Mount Method Cable Tie
