Panduit C-Style CU Comp Conn, #1 AWG Str– 2/0 AWG Str, 3/8” Rod (M); #6 AWG Sol- #2 AWG Str (T) [CTAPR2/0-2-X]; PAK668

Name: Panduit C-Style CU Comp Conn, #1 AWG Str– 2/0 AWG Str, 3/8” Rod (M); #6 AWG Sol- #2 AWG Str (T) [CTAPR2/0-2-X]; PAK668
Brand: Panduit
SKU: PAK668
Price: 576440.0 VND
Availability: InStock

Mã kho: PAK668

Mã nhà sản xuất: CTAPR2/0-2-X

Tên nhà sản xuất: Panduit

576.440₫ - 576.440₫

576.440₫

576.440₫ - 576.440₫

576.440₫

📩 Liên hệ để có giá tốt: CV@chanhvinh.com

Grounding Bonding / Grounding Compression Connectors Covers / E Style Connectors: Panduit CTAPR2/0-2-X

MÔ TẢ SẢN PHẨM

C-Style CU Comp Conn, #1 AWG Str– 2/0 AWG Str, 3/8” Rod (M); #6 AWG Sol- #2 AWG Str (T)

_THÔNG SỐ KỸ THUẬT:

Sub Brand	StructuredGround™
Overall Length (In.)	0.75
Overall Length (mm)	19
Material	High Conductivity Copper
Overall Width (In.)	0.72
Overall Width (mm)	18.3
Overall Height (In.)	1.43
Overall Height (mm)	36.3
Maximum Copper Conductor Size (AWG SOL)	1
Maximum Copper Conductor Size (AWG STR)	2/0
Minimum Copper Conductor Size (AWG SOL)	6
Minimum Copper Conductor Size (AWG STR)	6
Maximum Ground Rod Size (In.)	3/8
Maximum Ground Rod Size (mm)	9.52
Minimum Ground Rod Size (In.)	3/8
Minimum Ground Rod Size (mm)	9.52
Panduit Die Index Number	PO
Standards Met	cULus Listed for Direct Burial Grounding Applications to UL467 and Power Applications up to 35kV
Application	Utility/Ground Grid
Product Type	Compression Connectors - Taps
