Panduit C-Style CU Comp Conn, 300 kcmil– 500 kcmil, 3/4” Rod (M); #6 AWG Sol– 2/0 AWG Str (T) [CTAPR500-2/0-6]; PAK672

Name: Panduit C-Style CU Comp Conn, 300 kcmil– 500 kcmil, 3/4” Rod (M); #6 AWG Sol– 2/0 AWG Str (T) [CTAPR500-2/0-6]; PAK672
Brand: Panduit
SKU: PAK672
Availability: InStock

Mã kho: PAK672

Mã nhà sản xuất: CTAPR500-2/0-6

Tên nhà sản xuất: Panduit

0₫ - 0₫

0₫

0₫ - 0₫

0₫

📩 Liên hệ để có giá tốt: CV@chanhvinh.com

Grounding Bonding / Grounding Compression Connectors Covers / E Style Connectors: Panduit CTAPR500-2/0-6

MÔ TẢ SẢN PHẨM

The CTAPR500-2/0-6 Compression Connector Tap provides high-strength and premium electrical properties. It is suitable for use with solid and stranded copper Code conductors. Used for tapping conductor to conductor and conductor to ground rod applications. UL listed per UL486 for use suitable for dir

_THÔNG SỐ KỸ THUẬT:

Sub Brand	StructuredGround™
Overall Length (In.)	0.88
Overall Length (mm)	22.3
Material	High Conductivity Copper
Overall Width (In.)	1.23
Overall Width (mm)	31.2
Overall Height (In.)	2.42
Overall Height (mm)	61.5
Maximum Copper Conductor Size (AWG SOL)	3/0
Maximum Copper Conductor Size (AWG STR)	2/0
Maximum Copper Conductor Size (kcmil)	500
Minimum Copper Conductor Size (AWG SOL)	6
Minimum Copper Conductor Size (AWG STR)	6
Minimum Copper Conductor Size (kcmil)	300
Maximum Ground Rod Size (In.)	3/4
Maximum Ground Rod Size (mm)	19.05
Panduit Die Index Number	P500
Standards Met	cULus Listed for Direct Burial Grounding Applications to UL467 and Power Applications up to 35kV
Application	Utility/Ground Grid
Product Type	Compression Connectors - Taps
