Panduit Wire Termination, [DNF18250FIMX-2K]; PAI633

Name: Panduit Wire Termination, [DNF18250FIMX-2K]; PAI633
Brand: Panduit
SKU: PAI633
Price: 14130.0 VND
Availability: InStock

Mã kho: PAI633

Mã nhà sản xuất: DNF18250FIMX-2K

Tên nhà sản xuất: Panduit

14.130₫ - 14.130₫

14.130₫

14.130₫ - 14.130₫

14.130₫

📩 Liên hệ để có giá tốt: CV@chanhvinh.com

Wire Termination / Terminals Terminal Kits / Disconnects: Panduit DNF18250FIMX-2K

MÔ TẢ SẢN PHẨM

The vibration resistant male tab disconnect is made of brass and is nickel-plated. It is fully insulated in a red, nylon standard housing and has an expanded wire entry area. It has a tab size of 0.250 x 0.032" (6.3 x 0.8 mm) and supports a wire range of 22-18 AWG (0.5-1.0 mm²). It is 0.97" (24.6 mm

_THÔNG SỐ KỸ THUẬT:

Disconnect Type	Male Tab Disconnect
Insulation Material	Nylon - Barrel Insulated
Maximum Copper Conductor Size (AWG)	#22
Maximum Wire Size (AWG)	#22
Minimum Wire Size (AWG)	#18
Minimum Copper Conductor Size (AWG)	#18
Wire Strip Length (In.)	0.28
Wire Strip Length (mm)	7.1
Tab Size (In.)	0.25
Tab Size (mm)	6.3
Standards Met	UL 310 Listed, UL Listed 20H3 E78522; CSA Certified LR31212, C22.2 No.153
Maximum Voltage (V)	600
Base Material	Brass
Finish/Coating	Nickel
Color Code	Red
Flammability Rating	HB
Insulation Diameter (In.)	0.24
Insulation Diameter (mm)	6.2
Maximum Operating Temperature (°C)	105
Maximum Operating Temperature (°F)	221
Sub Brand	Reel Smart
Maximum Wire Insulation Diameter (In.)	0.244
Maximum Wire Insulation Diameter (mm)	6.2
Overall Height (In.)	0.29
Overall Height (mm)	7.4
Overall Length (In.)	0.97
Overall Length (mm)	24.6
Overall Width (In.)	0.41
Overall Width (mm)	10.4
Seam Type	Butted
Packaging Type	Reel
Product Type	Disconnects on a Reel
For Use With	CD9-8B, CD-800-8
Maximum Voltage (kV)	0.6
Part Features	• Continuously molded design provides reliable, consistent performance through the applicator for a high quality termination every time • Expanded wire entry designed to accommodate wire with a larger insulation thickness • Male tab couples with (all 0.250 x 0.032) female disconnects • Fully insulated design provides protection from electrical shorts • Male tab can be inserted and removed from the female disconnect without the use of tools for lower installed cost • Internal barrel serrations assure good wire contact and maximum tensile strength • UL Flammability UL 94V-2/HB, maximum insulation temperature 221°F (105°C) • UL and CSA rated up to 600 V per UL 310, where applicable
