Panduit FIG6-250-2

Panduit Grounding "Figure 6" Style Connector, 2 Str - 250 kcmil (35-120mm2), 1/2 - 5/8 Rod (12.7-15.9mm), or #3 - #4 Rebar (#10M-#13M) Main, 4 Sol - 2 Str (20-35mm2) Tap [FIG6-250-2]; PAL226

Mã kho: PAL226
Mã nhà sản xuất: FIG6-250-2
Tên nhà sản xuất: Panduit
0₫ - 0₫
0₫
0₫ - 0₫
0₫
📩 Liên hệ để có giá tốt: CV@chanhvinh.com

Grounding Bonding / Grounding Compression Connectors Covers / Cross Connectors: Panduit FIG6-250-2

MÔ TẢ SẢN PHẨM

Grounding "Figure 6" Style Connector, 2 Str - 250 kcmil (35-120mm2), 1/2 - 5/8 Rod (12.7-15.9mm), or #3 - #4 Rebar (#10M-#13M) Main, 4 Sol - 2 Str (20-35mm2) Tap

_THÔNG SỐ KỸ THUẬT:

Note NA
Sub Brand NA
Connector Type Fig.6 Connector
Overall Length (In.) 0.9
Overall Length (mm) 23.2
Material High Conductivity Copper
Overall Width (In.) 0.75
Overall Width (mm) 19.1
Overall Height (In.) 2.1
Overall Height (mm) 53.3
Maximum Copper Conductor Size (AWG SOL) 2
Maximum Copper Conductor Size (AWG STR) 2
Maximum Copper Conductor Size (AWG) NA
Maximum Copper Conductor Size (kcmil) 250
Minimum Copper Conductor Size (AWG SOL) 4
Minimum Copper Conductor Size (AWG STR) 4
Minimum Copper Conductor Size (AWG) NA
Maximum Ground Rod Size (In.) NA
Minimum Ground Rod Size (In.) 1/2
Minimum Ground Rod Size (mm) 12.7
Maximum Rebar Size (AWG) 4
Maximum Rebar Size (In.) 1/2
Maximum Rebar Size (mm) 12.7
Minimum Rebar Size (AWG) 3
Minimum Rebar Size (In.) 3/8
Minimum Rebar Size (mm) 9.5
Panduit Die Index Number PG25
Color Code Black
Standards Met cULus Listed to UL 467 for direct burial grounding applications iin earth or concrete. All parts are UL Listed to UL 486A/486B for power applications wire to wire combinations only.
Application Utility/Ground Grid
Product Type Grounding Fig. 6 Connector
