Panduit FIG6-5/8-26

Panduit Grounding "Figure 6" Style Connector, 1/2 - 5/8 Rod (12.7-15.9mm) Main, Quantity 1 or 2 Wires 6 Sol - 2 Sol (10-35mm2) Tap [FIG6-5/8-26]; PAL230

Mã kho: PAL230
Mã nhà sản xuất: FIG6-5/8-26
Tên nhà sản xuất: Panduit
0₫ - 0₫
0₫
0₫ - 0₫
0₫
📩 Liên hệ để có giá tốt: CV@chanhvinh.com

Grounding Bonding / Grounding Compression Connectors Covers / Cross Connectors: Panduit FIG6-5/8-26

MÔ TẢ SẢN PHẨM

Grounding "Figure 6" Style Connector, 1/2 - 5/8 Rod (12.7-15.9mm) Main, Quantity 1 or 2 Wires 6 Sol - 2 Sol (10-35mm2) Tap

_THÔNG SỐ KỸ THUẬT:

Note Connector can be used with one or two wires
Sub Brand NA
Connector Type Fig. 6 Connector
Overall Length (In.) 0.91
Overall Length (mm) 23.2
Material High Conductivity Copper
Overall Width (In.) 0.75
Overall Width (mm) 19.1
Overall Height (In.) 1.91
Overall Height (mm) 48.5
Maximum Copper Conductor Size (AWG SOL) 2
Maximum Copper Conductor Size (AWG STR) NA
Maximum Copper Conductor Size (AWG) NA
Minimum Copper Conductor Size (AWG SOL) 6
Minimum Copper Conductor Size (AWG STR) NA
Minimum Copper Conductor Size (AWG) NA
Maximum Ground Rod Size (In.) 5/8
Maximum Ground Rod Size (mm) 15.9
Minimum Ground Rod Size (In.) 1/2
Minimum Ground Rod Size (mm) 12.7
Maximum Rebar Size (AWG) NA
Maximum Rebar Size (In.) NA
Minimum Rebar Size (AWG) NA
Minimum Rebar Size (In.) NA
Panduit Die Index Number PG25
Color Code Black
Standards Met cULus Listed to UL 467 for direct burial grounding applications in earth or concrete. All parts are UL Listed to UL 486A/486B for power applications wire to ground rod combinations only.
Application Utility/Ground Grid
Product Type Grounding Fig. 6 Connector
