Panduit Black Polyethylene Cable Grommet 30.48m Long [GEE62F-A-C]; 412-1246

Name: Panduit Black Polyethylene Cable Grommet 30.48m Long [GEE62F-A-C]; 412-1246
Brand: Panduit
SKU: 4121246
Price: 1462710.0 VND
Availability: InStock

Mã kho: 4121246

Mã nhà sản xuất: GEE62F-A-C

Tên nhà sản xuất: Panduit

1.462.710₫ - 1.462.710₫

1.462.710₫

1.462.710₫ - 1.462.710₫

1.462.710₫

📩 Liên hệ để có giá tốt: CV@chanhvinh.com

Wire Routing Management Protection / Abrasion Protection / Grommet Edging: Panduit GEE62F-A-C

MÔ TẢ SẢN PHẨM

The GEE62F-A-C Polyethylene Slotted Grommet Edging protects and prevents wires and cables from chafing against sharp edges of panel walls and knockouts. Slotted edging recommended for use on irregularly shaped and round panel holes. The material is highly flexible, while the adhesive lining ensures

_THÔNG SỐ KỸ THUẬT:

Note	Designed for irregular shaped or round panel holes
Product Type	Slotted Grommet Edging
Color	Natural
Flammability Rating	UL94-HB
Material	Polyethylene
Maximum Compatible Panel Thickness (In.)	0.062
Maximum Compatible Panel Thickness (mm)	1.6
Maximum Operating Temperature (°C)	50
Maximum Operating Temperature (°F)	122
Minimum Compatible Panel Thickness (In.)	0.036
Minimum Compatible Panel Thickness (mm)	0.9
Minimum Operating Temperature (°C)	-40
Minimum Operating Temperature (°F)	-40
Overall Height (In.)	0.16
Overall Height (mm)	4.1
Overall Width (In.)	0.13
Overall Width (mm)	3.3
Overall Length (ft.)	100
Overall Length (m)	30.5
Resistance Properties	Abrasion Protection
Standards Met	RoHS Compliant
Application	To Protect and Prevent Wires and Cables from Chafing Against Sharp Edges of Panel Walls and Knockouts.
Part Features	Provides protection for cables being installed where there might be sharp edges with irregular shaped and round panel holes.
