Panduit LAMA Series Uninsulated Crimp Terminal, 5/8in Stud Size, Silver [LAMA1000-58-6Y]; 847-8757

Name: Panduit LAMA Series Uninsulated Crimp Terminal, 5/8in Stud Size, Silver [LAMA1000-58-6Y]; 847-8757
Brand: Panduit
SKU: 8478757
Availability: InStock

Mã kho: 8478757

Mã nhà sản xuất: LAMA1000-58-6Y

Tên nhà sản xuất: Panduit

0₫ - 0₫

0₫

0₫ - 0₫

0₫

📩 Liên hệ để có giá tốt: CV@chanhvinh.com

Wire Termination / Lugs Splices Split Bolts Accessories / Mechanical & Compression Lugs & Splices: Panduit LAMA1000-58-6Y

MÔ TẢ SẢN PHẨM

One-hole, aluminum, single barrel lug, type LAMA, 500 - 1000 kcmil, 5/8 (15.9mm) stud hole.

_THÔNG SỐ KỸ THUẬT:

Note	LAMA1000-58-6Y replaces LAMA1000-58-6
Product Type	Mechanical Connectors - Lugs
Stud Hole Size (In.)	5/8
Number of Holes	1
Tongue Type	Straight
Tongue Length (In.)	1.88
Tongue Length (mm)	44.5
Tongue Thickness (In.)	0.5
Tongue Thickness (mm)	11.2
Tongue Width (In.)	1.75
Tongue Width (mm)	44.5
Overall Height (In.)	1.9
Overall Height (mm)	54.1
Overall Length (In.)	3.5
Overall Length (mm)	88.9
Standards Met	UL Listed and CSA Certified for use up to 600 V and UL temperature rated 90°C
UL Temperature Rating (°C)	90
Hex Size (mm)	14.3
Sub Brand	Pan-Lug
Part Features	Made from high strength, extruded aluminum alloy to provide premium electrical and mechanical performance.
