Panduit LCAX Series Uninsulated Tubular Ring Terminal, 1/2in Stud Size, Silver [LCAX300-12-6]; 847-8846

Name: Panduit LCAX Series Uninsulated Tubular Ring Terminal, 1/2in Stud Size, Silver [LCAX300-12-6]; 847-8846
Brand: Panduit
SKU: 8478846
Price: 573540.0 VND
Availability: InStock

Mã kho: 8478846

Mã nhà sản xuất: LCAX300-12-6

Tên nhà sản xuất: Panduit

573.540₫ - 573.540₫

573.540₫

573.540₫ - 573.540₫

573.540₫

📩 Liên hệ để có giá tốt: CV@chanhvinh.com

Wire Termination / Lugs Splices Split Bolts Accessories / Mechanical & Compression Lugs & Splices: Panduit LCAX300-12-6

MÔ TẢ SẢN PHẨM

One-hole, flex lug, 300 kcmil cable, 1/2 stud hole.

_THÔNG SỐ KỸ THUẬT:

Product Type	Tin-Plated Copper Compression Connectors - Lugs
Sub Brand	Pan-Lug
Stud Hole Size (In.)	42.767
Stud Hole Size (mm)	12.7
Barrel Type	Standard Barrel Length with Inspection Window
Barrel Length (In.)	1.19
Barrel Length (mm)	30.2
Tongue Type	Standard Tongue Width
Tongue Width (In.)	1.39
Tongue Width (mm)	35.3
Tongue Angle	Straight
Tongue Thickness (In.)	0.18
Tongue Thickness (mm)	4.6
Overall Length (In.)	2.91
Overall Length (mm)	73.9
Color Code	Red
Panduit Die Index Number	P71
Burndy Die Index Number	18
Wire Strip Length (In.)	1.25
Wire Strip Length (mm)	31.8
Part Features	Tin plated to inhibit corrosion,color coded barrel,inspection window, beveled wire entry.
