Panduit lugs [LCD2/0-14BH-X], PAE032
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| _THÔNG SỐ KỸ THUẬT: | |
|---|---|
| Copper Conductor Size (kcmil) | 133.1 |
| Copper Conductor Size (AWG) | 2/0 |
| Product Type | Tin-Plated Copper Compression Connectors - Lugs |
| Stud Hole Size (In.) | 42.826 |
| Stud Hole Size (mm) | 6.4 |
| Stud Hole Spacing (In.) | 0.75 |
| Stud Hole Spacing (mm) | 19.1 |
| Barrel Type | Standard Barrel Length with Inspection Window |
| Barrel Length (mm) | 24.9 |
| Barrel Length (In.) | 0.98 |
| Tongue Type | Standard |
| Tongue Width (In.) | 0.85 |
| Tongue Width (mm) | 21.6 |
| Tongue Thickness (mm) | 3.3 |
| Tongue Thickness (In.) | 0.13 |
| Overall Length (mm) | 64 |
| Overall Length (In.) | 2.52 |
| Color Code | Black |
| Panduit Die Index Number | P45 |
| Burndy Die Index Number | 13 |
| Wire Strip Length (mm) | 27 |
| Wire Strip Length (In.) | 1.06 |
| Sub Brand | Pan-Lug |
| Part Features | Tin plated to inhibit corrosion,color coded barrel,inspection window, NEBS level 3. |
