Panduit Splicer/Reducer, dual rated for use with copper or aluminum conductors, 1/0 STR - #14 SOL. [PISR1/0-1]; PAN975

Name: Panduit Splicer/Reducer, dual rated for use with copper or aluminum conductors, 1/0 STR - #14 SOL. [PISR1/0-1]; PAN975
Brand: Panduit
SKU: PAN975
Price: 837240.0 VND
Availability: InStock

Mã kho: PAN975

Mã nhà sản xuất: PISR1/0-1

Tên nhà sản xuất: Panduit

837.240₫ - 837.240₫

837.240₫

837.240₫ - 837.240₫

837.240₫

📩 Liên hệ để có giá tốt: CV@chanhvinh.com

Wire Termination / Lugs Splices Split Bolts Accessories / Splices: Panduit PISR1/0-1

MÔ TẢ SẢN PHẨM

Splicer/Reducer, dual rated for use with copper or aluminum conductors, 1/0 STR - #14 SOL.

_THÔNG SỐ KỸ THUẬT:

Product Type	Multi-Tap Connectors, In-Line Splicer/Reducer
Sub Brand	Pan-Lug
Insulation Material	Clear PVC
Standards Met	CSA CERTIFIED/UL LISTED
Overall Length (In.)	2.91
Overall Length (mm)	73.9
Overall Width (In.)	0.95
Overall Width (mm)	24.1
Overall Height (In.)	1.4
Overall Height (mm)	35.8
Wire Strip Length (In.)	0.94
Wire Strip Length (mm)	23.9
Part Features	Each port pre-filled with oxide inhibiting joint compound seals out air and moisture to deter surface oxidation
