The pan-post standoff is black and requires a #10 (M5) screw. It measures 1.06" long x 0.72" wide x 4.60" high (26.9 x 18.3 x 116.9 mm). It is used with miniature, intermediate, and standard cable ties. It comes in packages of 100.

Mã kho: PAO059
Tên nhà sản xuất: Panduit
Original price 37.410₫ - Original price 37.410₫
Original price
37.410₫
37.410₫ - 37.410₫
Current price 37.410₫
📩 Liên hệ để có giá tốt: CV@chanhvinh.com

Wire Routing Management Protection / Cable Wire Ties Mounts Straps / Cable Tie Mounts: Panduit PP2S-S10-C0

MÔ TẢ SẢN PHẨM

The pan-post standoff is black and requires a #10 (M5) screw. It measures 1.06" long x 0.72" wide x 4.60" high (26.9 x 18.3 x 116.9 mm). It is used with miniature, intermediate, and standard cable ties. It comes in packages of 100.

_THÔNG SỐ KỸ THUẬT:

Application Pan-Post ™ Standoff Supports Cable Bundles Above or Away from Surface
Product Type Cable Tie Mount
Color Black
Flammability Rating UL94V-2
Environment Indoor
Material Nylon 6.6
Maximum Operating Temperature (°C) 85
Maximum Operating Temperature (°F) 185
Minimum Operating Temperature (°C) -60
Minimum Operating Temperature (°F) -76
Mount Method Screw
Mounting Hole Thread Size #10
Overall Height (In.) 4.6
Overall Height (mm) 116.8
Overall Length (In.) 4.6
Overall Length (mm) 116.8
Overall Width (In.) 0.72
Overall Width (mm) 50.3
Resistance Properties UV Resistant
Standards Met CE Compliant, UL Recognized: E136577, RoHS Compliant
Sub Brand Pan-Post™
For Use With Miniature, Intermediate, Standard Cross-Section Ties
