Panduit Spiral Wrap, offers abrasion protection for wires, cables, hoses and tubing, .50" (12.7mm) x 100', flame retardant polyethylene, natural, standard package. [T50FR-CY]; PAP250

Name: Panduit Spiral Wrap, offers abrasion protection for wires, cables, hoses and tubing, .50" (12.7mm) x 100', flame retardant polyethylene, natural, standard package. [T50FR-CY]; PAP250
Brand: Panduit
SKU: PAP250
Price: 9013640.0 VND
Availability: InStock

Mã kho: PAP250

Mã nhà sản xuất: T50FR-CY

Tên nhà sản xuất: Panduit

9.013.640₫ - 9.013.640₫

9.013.640₫

9.013.640₫ - 9.013.640₫

9.013.640₫

📩 Liên hệ để có giá tốt: CV@chanhvinh.com

Wire Routing Management Protection / Abrasion Protection / Cable Sleeves Tools Wraps: Panduit T50FR-CY

MÔ TẢ SẢN PHẨM

The T50FR-CY Polyethylene Spiral Wrap provides continuous abrasion protection for wires, cables, and tubing. The wrap harnesses multiple cables into a single manageable bundle while allowing for breakouts. Lightweight, flexible, durable protection for use with irregular shapes. Installation tool sup

_THÔNG SỐ KỸ THUẬT:

Application	Harness Multiple Cables Into a Single Manageable Bundle; Allows Breakouts of Single/Multiple Cables; Provides Abrasion Protection for Wire, Cables, Hoses, and Tubing
Note	T50FR-CY replaces T50FR-C
Product Type	Spiral Wrap
Color	Natural
Environment	Indoor
Flammability Rating	UL94V-0
Includes	Installation Tool
Material	Flame Retardant Polyethylene
Resistance Properties	Abrasion Resistance; Flame Retardant
Maximum Bundle Diameter (In.)	4
Maximum Bundle Diameter (mm)	101.6
Maximum Operating Temperature (°C)	50
Maximum Operating Temperature (°F)	122
Minimum Bundle Diameter (In.)	0.375
Minimum Bundle Diameter (mm)	9.5
Minimum Operating Temperature (°C)	-20
Minimum Operating Temperature (°F)	-4
Outer Diameter (In.)	0.5
Outer Diameter (mm)	12.7
Overall Length (ft.)	100
Overall Length (m)	30.5
Standards Met	UL Recognized - E141152; UL94V-0
Wall Thickness (In.)	0.06
Wall Thickness (mm)	1.52
Part Features	Allows breakouts of single/multiple cables, Provides abrasion protection for wire, cables, hoses and tubing. Multiple colors allow for easy identification of cable bundles. Installation tool is supplied and the spiral wrap is reusable.

Panduit Spiral Wrap, offers abrasion protection for wires, cables, hoses and tubing, .50" (12.7mm) x 100', flame retardant polyethylene, natural, standard package. [T50FR-CY]; PAP250

MÔ TẢ SẢN PHẨM

_THÔNG SỐ KỸ THUẬT:
