| THÔNG SỐ KỸ THUẬT |
|---|
| Manufacturer |
Pickering Electronics |
| Manufacturer Part No. |
100-1-C-5/3D |
| Type of relay |
reed switch |
| Contacts configuration |
SPDT |
| Rated coil voltage |
5V DC |
| Contact current max. |
1.2A |
| Switched voltage |
max. 200V DC |
| Switching capacity |
3W |
| Coil resistance |
3.3kΩ |
| Mounting |
THT |
| Manufacturer series |
100 |
| Contact resistance |
0.2Ω |
| Operating temperature |
-20...85°C |
| Operate time |
1ms |
| Release time |
1ms |
| Switched current |
0.25A |
| Min. insulation resistance |
1TΩ |
| Breakdown voltage |
200V |
| Body dimensions |
24.1x12.7x10.2mm |
| Terminal pitch |
2.54mm |
| Optional equipment |
diode |
| Electrical life |
100000000 cycles |
| Gross weight |
6.6 g |
Tài liệu: Documentation EN
Giá: Liên hệ – gửi mã và số lượng về [email protected] để nhận báo giá nhanh.
