Renesas Electronics HD64F2345F20-V, 16/32bit H8S/2000 Microcontroller, 20MHz, 128 kB Flash, 100-Pin PQFP [HD64F2345F20-V]; 546-7688
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Family Name | H8S |
| Package Type | PQFP |
| Mounting Type | Surface Mount |
| Pin Count | 100 |
| Device Core | H8S/2000 |
| Data Bus Width | 16/32bit |
| Program Memory Size | 128 kB |
| Maximum Frequency | 20MHz |
| RAM Size | 4 kB |
| Number of PWM Units | 2 |
| ADC Channels | 8 |
| Typical Operating Supply Voltage | 4.5 → 5.5 V |
| Maximum Operating Temperature | +75 °C |
| Number of ADC Units | 1 |
| Instruction Set Architecture | CISC |
| ADC Resolution | 10bit |
| Number of Timers | 8 |
| Program Memory Type | Flash |
| Dimensions | 14 x 14 x 2.7mm |
| Timers | 2 x 8 bit, 6 x 16 bit |
| Height | 2.7mm |
| Timer Resolution | 8 bit, 16 bit |
| Minimum Operating Temperature | -20 °C |
| Length | 14mm |
| ADCs | 8 x 10 bit |
| Width | 14mm |
| Pulse Width Modulation | 2(PWM) |
