ROHM 2SCR586DGTL NPN Transistor, 5 A, 80 V, 3+Tab-Pin DPAK [2SCR586DGTL]; 128-8843
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Transistor Type | NPN |
| Maximum DC Collector Current | 0.208333333333333 |
| Maximum Collector Emitter Voltage | 80 V |
| Package Type | DPAK (TO-252) |
| Mounting Type | Surface Mount |
| Maximum Power Dissipation | 10 W |
| Minimum DC Current Gain | 120 |
| Transistor Configuration | Common Emitter |
| Maximum Collector Base Voltage | 80 V |
| Maximum Emitter Base Voltage | 6 V |
| Maximum Operating Frequency | 100 MHz |
| Pin Count | 3+Tab |
| Number of Elements per Chip | 1 |
| Height | 2.5mm |
| Maximum Operating Temperature | +150 °C |
| Length | 6.7mm |
| Dimensions | 6.7 x 5.8 x 2.5mm |
| Maximum Collector Emitter Saturation Voltage | 300 mV |
| Width | 5.8mm |
