BU7241G-TR ROHM, CMOS, Op Amp, RRIO, 900kHz, 5 V, 5-Pin SSOP [BU7241G-TR]; 131-2777
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Amplifier Type | CMOS |
| Mounting Type | Surface Mount |
| Package Type | SSOP |
| Power Supply Type | Single |
| Number of Channels per Chip | 1 |
| Pin Count | 5 |
| Typical Single Supply Voltage | 5 V |
| Typical Gain Bandwidth Product | 900kHz |
| Typical Slew Rate | 0.4V/µs |
| Maximum Operating Temperature | +85 °C |
| Minimum Operating Temperature | -40 °C |
| Rail to Rail | Rail to Rail Input/Output |
| Maximum Input Voltage | 5.5 V |
| Width | 1.6mm |
| Output Current | 10 (Source) mA, 12 (Sink) mA |
| Input Offset Current | 1pA |
| Height | 1.1mm |
| Offset Voltage | 10mV |
| Typical Voltage Gain | 95 dB |
| Minimum Input Voltage | +1.8 V |
| Input Voltage Range | 1.8 → 5.5 V |
| Dimensions | 2.9 x 1.6 x 1.1mm |
| Length | 2.9mm |
