R6020JNXC7G N-Channel MOSFET, 20 A, 600 V R6020JNX, 3-Pin TO-220FM ROHM [R6020JNXC7G]; 183-5935
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Channel Type | N |
| Maximum Continuous Drain Current | 20 A |
| Maximum Drain Source Voltage | 600 V |
| Package Type | TO-220FM |
| Mounting Type | Through Hole |
| Pin Count | 3 |
| Maximum Drain Source Resistance | 230 mΩ |
| Channel Mode | Enhancement |
| Maximum Gate Threshold Voltage | 7V |
| Minimum Gate Threshold Voltage | 5V |
| Maximum Power Dissipation | 76 W |
| Transistor Configuration | Single |
| Maximum Gate Source Voltage | ±30 V |
| Number of Elements per Chip | 1 |
| Typical Gate Charge @ Vgs | 45 nC @ 15 V |
| Height | 16.27mm |
| Series | R6020JNX |
| Maximum Operating Temperature | 150 °C |
| Length | 10.3mm |
| Width | 5mm |
| Minimum Operating Temperature | -55 °C |
