RSD201N10TL N-Channel MOSFET, 20 A, 100 V RSD201N10, 3+Tab-Pin SOT-428 ROHM [RSD201N10TL]; 133-2839
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Channel Type | N |
| Maximum Continuous Drain Current | 20 A |
| Maximum Drain Source Voltage | 100 V |
| Package Type | SOT-428 |
| Mounting Type | Surface Mount |
| Pin Count | 3 + Tab |
| Maximum Drain Source Resistance | 84 mΩ |
| Channel Mode | Enhancement |
| Maximum Gate Threshold Voltage | 2.5V |
| Minimum Gate Threshold Voltage | 1V |
| Maximum Power Dissipation | 20 W |
| Transistor Configuration | Single |
| Maximum Gate Source Voltage | -20 V, +20 V |
| Number of Elements per Chip | 1 |
| Height | 2.5mm |
| Width | 5.8mm |
| Length | 6.7mm |
| Forward Diode Voltage | 1.5V |
| Maximum Operating Temperature | +150 °C |
| Series | RSD201N10 |
| Typical Gate Charge @ Vgs | 55 nC @ 10 V |
