RS PRO 3 Core 2.5 mm², 4 mm² Mains Power Cable, Grey Polyvinyl Chloride PVC Sheath 50m, 20 A 300 V,; 122-3068
Mã kho: 1223068
Tên nhà sản xuất:
RS PRO
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Number of Cores | 3 |
| Cross Sectional Area | 2.5 mm², 4 mm² |
| Sheath Colour | Grey |
| Current Rating | 20 A |
| Length | 50m |
| Voltage Rating | 300 V |
| Outer Diameter | 10.8mm |
| Sheath Material | Polyvinyl Chloride PVC |
| Maximum Operating Temperature | +80°C |
| Conductor Strand Type | Stranded |
| Standards Met | RoHS Compliant |
| Size of Strands | 0.008 mm |
| Conductor Material | Copper |
| Conductor Resistance | <4.7 (1 Core) Ω/km, <7.6 (2 Core) Ω/km |
| Core Strands | 50/0.008 mm |
| Number of Strands | 50 (2 Core), 56 (1 Core) |
| Insulation Material | PVC |
