RS PRO ILCM03A Clamp Meter, Max Current 60A ac; 123-2204
Mã kho: 1232204
Tên nhà sản xuất:
RS PRO
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Absolute Maximum AC Current Measurement | 60A ac |
| Absolute Maximum AC Voltage Measurement | 400V ac |
| Absolute Maximum Resistance Measurement | 400Ω |
| Model Number | ILCM03A |
| AC Current Measurement Resolution | 10µA |
| Clamp Meter Type | Leakage Current Clamp |
| Best AC Current Accuracy | ±(1% rdg + 3dgts) |
| Best AC Voltage Accuracy | ±(1.5% rdg + 2dgts) |
| Functions Measured | AC Current, AC Voltage, Resistance |
| Battery Type | 1.5 V |
| Dimensions | 62 x 35.6 x 210mm |
| DC Voltage Measurement Resolution | 100mV |
| Weight | 200g |
| Resistance Measurement Resolution | 100mΩ |
| Best Resistance Measurement Accuracy | ±1 % ± 2 Digits |
| Display Type | LCD |
| Maximum Operating Temperature | +50°C |
| Power Source | Battery |
| AC Voltage Measurement Resolution | 100mV |
| Width | 35.6mm |
| Jaw Capacity Busbars | 30mm |
| Maximum Conductor Size | 30mm |
| Length | 62mm |
| Minimum Operating Temperature | -10°C |
| Height | 210mm |
