RS PRO Multi Function Time Delay Relay, 11-Pin Connector, 0.6 s → 60 min, 1 Contacts, SPDT; 161-7612
Mã kho: 1617612
Tên nhà sản xuất:
RS PRO
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Supply Voltage | 10.5 → 265 V ac/dc |
| Time Range | 0.6 s → 60 min |
| Mode of Operation | Off Pulse, ON Pulse with Control Switch, ON Pulse without Control Switch, On-Off Pulse |
| Mounting Type | Plug In |
| Number of Timer Functions | Multi Function |
| Number of Contacts | 1 |
| Time Increment | Minutes, Seconds |
| Power Supply | External |
| Current Maximum | 0.333333333333333 |
| Terminal Type | 11-Pin Connector |
| Minimum Voltage | 10.5 V ac/dc |
| Maximum Voltage | 265 V ac/dc |
| Switch Configuration | SPDT |
| Maximum Operating Temperature | +55°C |
| Contact Material | Silver Nickel |
| Depth | 59.5mm |
| Minimum Operating Temperature | -20°C |
| Length | 27mm |
| Width | 75mm |
| Time Delay | 100 ms |
