RS PRO 470μF 100V dc Aluminium Electrolytic Capacitor, Through Hole 22 (Dia.) x 30mm +105°C 22mm 10mm 30mm; 170-1030
Mã kho: 1701030
Tên nhà sản xuất:
RS PRO
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 470 µF |
| Voltage | 100 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 22 (Dia.) x 30mm |
| Height | 30mm |
| Length | 30mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 22mm |
| Maximum Operating Temperature | +105°C |
| Lifetime | 2000h |
| Lead Pitch | 10mm |
| Series | RS |
| Polarised | Polar |
| Dissipation Factor | 0.1 |
| Tolerance | ±20% |
| Leakage Current | <=0.02 CV @ 5 min |
| Ripple Current | 900mA |
