RS PRO 37 Way Right Angle Through Hole PCB D-sub Connector Socket, 2.77mm Pitch; 528-3733
Mã kho: 5283733
Tên nhà sản xuất:
RS PRO
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Number of Contacts | 37 |
| Gender | Female |
| Body Orientation | Right Angle |
| Mounting Type | Through Hole |
| Pitch | 2.77mm |
| Termination Method | Solder |
| Current Rating | 5.0A |
| Housing Material | Steel |
| Voltage Rating | 250 V ac |
| Length | 69.32mm |
| Width | 4.1mm |
| Depth | 12.55mm |
| Dimensions | 69.32 x 4.1 x 12.55mm |
| Maximum Operating Temperature | +125°C |
| Contact Plating | Gold over Nickel |
| Series Number | 528 |
| Contact Material | Copper Alloy |
| Minimum Operating Temperature | -55.0°C |
