RS PRO 5 Core 2.5 mm² Power Cable, Grey Polyvinyl Chloride PVC Sheath 100m, 300 V, 500 V, NYM-J; 902-8350
Mã kho: 9028350
Tên nhà sản xuất:
RS PRO
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Number of Cores | 5 |
| Cross Sectional Area | 2.5 mm² |
| Sheath Colour | Grey |
| Length | 100m |
| Voltage Rating | 300 V, 500 V |
| Outer Diameter | 11.5 → 14mm |
| Sheath Material | Polyvinyl Chloride PVC |
| Type | NYM-J |
| Minimum Operating Temperature | -5°C |
| Maximum Operating Temperature | +70°C |
| Conductor Strand Type | Solid |
| Insulation Material | PVC |
| Fire Behaviour | Flame Retardant |
| Size of Strands | 1.75 mm |
| Standards Met | HD 21.4 S2, IEC 60288, IEC 60332-1 |
| Conductor Resistance | 7.41 Ω/km |
