Schaffner FN 660 Series 16A 250 V ac 400Hz Flange Mount RFI Filter, with Screw Terminals, Single Phase [FN660-16-06]; 167-6737
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Maximum Current Rating | 16A |
| Maximum Voltage Rating | 250 V ac |
| Mounting Type | Flange Mount |
| Termination Style | Screw |
| Number of Phases | 1 |
| Number of Stages | Two Stage |
| Series | FN 660 |
| Operating Frequency | 400Hz |
| Length | 54mm |
| Depth | 85mm |
| Height | 40.3mm |
| Capacitance | 2.2 nF, 150 nF |
| Dimensions | 54 x 85 x 40.3mm |
| Inductance | 0.44 x 2 mH |
| Minimum Operating Temperature | -25°C |
| Maximum Operating Temperature | +100°C |
| Resistance | 1MΩ |
