Schneider Electric 20 A SPNO Solid State Relay, Zero Voltage, DIN Rail, SCR, 280 V ac Maximum Load [SSM1A120BD]; 179-9449
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Minimum Load Current | 0.15 A |
| Maximum Load Current | 20 A |
| Range | Zelio Relay |
| Series | SSM1 |
| Mounting Type | DIN Rail |
| Minimum Load Voltage | 24 V ac |
| Maximum Load Voltage | 280 V ac |
| Minimum Control Voltage | 4 V dc |
| Maximum Control Voltage | 32 V dc |
| Switching Type | Zero voltage |
| Contact Configuration | SPNO |
| Terminal Type | Screw |
| Output Device | SCR |
| Maximum Turn On Time | 0.5 cycles |
| Dimensions | 22.5 x 97.7 x 98.8mm |
| Maximum Operating Temperature | +80°C |
| Capacitance | 8pF |
| Height | 98.8mm |
| Minimum Operating Temperature | -40°C |
| Length | 22.5mm |
| Off State Leakage Current | 10 mA |
| Control Voltage Range | 4 → 32 V dc |
| Depth | 97.7mm |
| Special Features | Single Phase Relay |
| Relay Type | Solid State Relay |
| Operating Temperature Range | -40 → +80°C |
| Load Voltage Range | 24 → 280V ac |
