Semikron, SKKH 72/16 E, Diode/Thyristor Module SCR, SCR, 70A 1600V, 5-Pin A 43a [SKKH 72/16 E]; 905-6119
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Thyristor Type | SCR |
| Maximum Gate Trigger Voltage | 2 (Min)V |
| Maximum Gate Trigger Current | 150 (Min)mA |
| Maximum Holding Current | 500mA |
| Rated Average On-State Current | 70A |
| Repetitive Peak Reverse Voltage | 1600V |
| Surge Current Rating | 9000A |
| Mounting Type | Panel Mount |
| Package Type | A 43a |
| Pin Count | 5 |
| Peak On-State Voltage | 1.6V |
| Repetitive Peak Forward Blocking Voltage | 1600V |
| Repetitive Peak Off-State Current | 100mA |
| Dimensions | 115 x 50.3 x 52mm |
| Minimum Operating Temperature | -40 °C |
| Length | 115mm |
| Maximum Operating Temperature | +130 °C |
| Height | 52mm |
| Width | 50.3mm |
