Sensata / Crydom 15 A Solid State Relay, Zero Crossing, Panel Mount, 280 Vrms Maximum Load [10PCV2415]; 145-0561
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Minimum Load Current | 150 mA |
| Maximum Load Current | 15 A |
| Series | PCV |
| Mounting Type | Panel Mount |
| Minimum Load Voltage | 100 Vrms |
| Maximum Load Voltage | 280 Vrms |
| Minimum Control Voltage | 2 V dc |
| Maximum Control Voltage | 10 V dc |
| Switching Type | Zero Crossing |
| Terminal Type | Screw |
| Dimensions | 45.7 x 58.4 x 23mm |
| Relay Type | Solid State Relay |
| Standards Met | CE, CSA LR 81689-73, CULus |
| Special Features | For use with Resistive Loads Only, Proportional Controller |
| Depth | 58.4mm |
| Load Voltage Range | 60 → 280Vrms |
| Control Voltage Range | 2 → 10 V dc |
| Operating Temperature Range | -30 → +80°C |
| Length | 45.7mm |
| Off State Leakage Current | 10 mArms |
| Maximum Operating Temperature | +80°C |
| Height | 23mm |
| Number of Poles | 1 |
| Minimum Operating Temperature | -30°C |
