Sensata / Crydom 30 A SPST Solid State Relay, Instantaneous, DIN Rail, SCR, 280 V rms Maximum Load [CKRD4830-10]; 736-0835
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Minimum Load Current | 0.15 A rms |
| Maximum Load Current | 30 A |
| Mounting Type | DIN Rail |
| Minimum Load Voltage | 24 V rms |
| Maximum Load Voltage | 280 V rms |
| Minimum Control Voltage | 4 V dc |
| Maximum Control Voltage | 32 V dc |
| Switching Type | Instantaneous |
| Contact Configuration | SPST |
| Terminal Type | Screw |
| Output Device | SCR |
| Maximum Turn On Time | 10 ms |
| Dimensions | 22.5 x 81.3 x 81.9mm |
| Minimum Operating Temperature | -40°C |
| Length | 22.5mm |
| Off State Leakage Current | 10 mA rms |
| Load Voltage Range | 24 → 280Vrms |
| Operating Temperature Range | -40 → +80°C |
| Control Voltage Range | 4 → 32 V dc |
| Height | 81.9mm |
| Maximum Operating Temperature | +80°C |
| Depth | 81.3mm |
