Sensata / Crydom 65 A SPST Solid State Relay, Instantaneous, DIN Rail, SCR, 530 V rms Maximum Load [CMRD4865-10]; 736-0845
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Minimum Load Current | 0.15 A rms |
| Maximum Load Current | 65 A |
| Mounting Type | DIN Rail |
| Minimum Load Voltage | 48 V rms |
| Maximum Load Voltage | 530 V rms |
| Minimum Control Voltage | 3 V dc |
| Maximum Control Voltage | 32 V dc |
| Switching Type | Instantaneous |
| Contact Configuration | SPST |
| Terminal Type | Screw |
| Output Device | SCR |
| Maximum Turn On Time | 1/2 cycle |
| Dimensions | 44.5 x 76.2 x 76.2mm |
| Operating Temperature Range | -40 → +80°C |
| Control Voltage Range | 3 → 32 V dc |
| Load Voltage Range | 48 → 530Vrms |
| Depth | 76.2mm |
| Minimum Operating Temperature | -40°C |
| Height | 76.2mm |
| Maximum Operating Temperature | +80°C |
| Length | 44.5mm |
| Off State Leakage Current | 10 mA rms |
