Sensata / Crydom 25 A Solid State Relay, Zero Crossing, Panel Mount, SCR, 280 V ac Maximum Load [CSW2425K]; 145-0567
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Minimum Load Current | 150 mA rms |
| Maximum Load Current | 25 A |
| Mounting Type | Panel Mount |
| Series | CSW |
| Minimum Load Voltage | 24 V ac |
| Maximum Load Voltage | 280 V ac |
| Minimum Control Voltage | 3 V dc |
| Maximum Control Voltage | 32 V dc |
| Switching Type | Zero Crossing |
| Terminal Type | Screw |
| Output Device | SCR |
| Maximum Turn On Time | 1/2 cycles |
| Dimensions | 44.5 x 57.3 x 26.4mm |
| Minimum Operating Temperature | -40°C |
| Operating Temperature Range | -40 → +80°C |
| Off State Leakage Current | 1 mArms |
| Maximum Operating Temperature | +80°C |
| Capacitance | 10pF |
| Height | 26.4mm |
| Length | 44.5mm |
| Standards Met | CE, CSA LR 81689, CULus Recognised E116949, EMC Compliant, IEC, IEC 60068-2-27, IEC 60068-2-6, IEC 61000-4-2, IEC 61000-4-4, IEC 62314, UL 94 V-0, VDE Approved 10143 UG |
| Special Features | Direct Bond Copper Substrate, Direct Power Lead Frame, Epoxy-Free Design, Low Off-State Leakage Current |
| Number of Poles | 1 |
| Depth | 57.3mm |
| Control Voltage Range | 3 → 32 V dc |
| Load Voltage Range | 24 → 280V ac |
| Relay Type | Solid State Relay |
