Sensata / Crydom 7.6 Arms Solid State Relay, Zero Crossing, DIN Rail, 415 V ac Maximum Load [DRC3R40D420]; 145-0581
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Minimum Load Current | 0.15 A rms |
| Maximum Load Current | 7.6 Arms |
| Mounting Type | DIN Rail |
| Series | DRC |
| Minimum Load Voltage | 48 V ac |
| Maximum Load Voltage | 415 V ac |
| Minimum Control Voltage | 18 V ac/dc |
| Maximum Control Voltage | 30 V ac/dc |
| Switching Type | Zero Crossing |
| Terminal Type | Screw |
| Maximum Turn On Time | 30 ms |
| Dimensions | 45.3 x 95.6 x 86.7mm |
| Length | 45.3mm |
| Off State Leakage Current | 5.5 mArms |
| Maximum Operating Temperature | +80°C |
| Capacitance | 20pF |
| Number of Poles | 3 |
| Relay Type | Solid State Relay |
| Standards Met | CCCs, CE, CSA C22.2 No. 14, CULus Listed E116949, EMC Compliant, EN/IEC 60947-4-2, IEC, IEC 60068-2-27, IEC 60068-2-6, IEC 61000-4-2, IEC 61000-4-4, UL |
| Special Features | AC or DC Control, Built-In Overvoltage Protection, LED Input Status Indicator, Ultra-Efficient Thermal Management Design |
| Control Voltage Range | 18 → 30 V ac/dc |
| Load Voltage Range | 48 → 415V ac |
| Operating Temperature Range | -30 → +80°C |
| Depth | 95.6mm |
| Minimum Operating Temperature | -30°C |
| Height | 86.7mm |
