Sensata / Crydom 50 Arms Solid State Relay, Zero Crossing, Panel Mount, 600 V ac Maximum Load [GN350ESZ]; 145-0548
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Minimum Load Current | 100 mA rms |
| Maximum Load Current | 50 A rms |
| Mounting Type | Panel Mount |
| Series | GN3 |
| Minimum Load Voltage | 48 V ac |
| Maximum Load Voltage | 600 V ac |
| Minimum Control Voltage | 18 V ac |
| Maximum Control Voltage | 36 V ac |
| Switching Type | Zero Crossing |
| Terminal Type | Screw |
| Maximum Turn On Time | 30 ms |
| Dimensions | 103.9 x 79.7 x 36.83mm |
| Special Features | Direct Bond Copper Substrate, IP20 Touch-Safe Cover, LED Input Status Indicator, Transient Protection Built-In |
| Standards Met | CE, CSA LR 38595, CULus Recognised E79183, EN 60950-1, IEC 1000-4-2, IEC 1000-4-3, IEC 1000-4-4, IEC 1000-4-5, IEC 1000-4-6, IEC 60068-2-2, IEC 60068-2-6, IEC 62314, TUV, UL, UL 94 V-0 |
| Relay Type | Solid State Relay |
| Number of Poles | 3 |
| Off State Leakage Current | 0.06 mArms |
| Length | 103.9mm |
| Operating Temperature Range | -40 → +80°C |
| Control Voltage Range | 18 → 36 V ac |
| Load Voltage Range | 48 → 600V ac |
| Depth | 79.7mm |
| Minimum Operating Temperature | -40°C |
| Height | 36.83mm |
| Capacitance | 8pF |
| Maximum Operating Temperature | +80°C |
