Silicon Labs EFM32WG360F64G-A-CSP81, 32bit ARM Cortex M4 MCU, 48MHz, 64 kB Flash, 81-Pin CSP [EFM32WG360F64G-A-CSP81]; 865-9887
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Family Name | EFM32WG |
| Package Type | CSP |
| Mounting Type | Surface Mount |
| Pin Count | 81 |
| Device Core | ARM Cortex M4 |
| Data Bus Width | 32bit |
| Program Memory Size | 64 kB |
| Maximum Frequency | 48MHz |
| RAM Size | 32 kB |
| USB Channels | 1 x OTG |
| ADC Channels | 4, 8 |
| Number of SPI Channels | 1 |
| Typical Operating Supply Voltage | 1.98 → 3.8 V |
| Number of I2C Channels | 2 |
| Number of Timers | 4 |
| Height | 0.379mm |
| Width | 4.275mm |
| Timers | 4 x 16 bit |
| Dimensions | 4.355 x 4.275 x 0.379mm |
| Timer Resolution | 16bit |
| ADCs | 4-ch x 12-bit, 8-ch x 12-bit |
| Length | 4.36mm |
| Maximum Operating Temperature | +85 °C |
| Number of ADC Units | 1 |
| Instruction Set Architecture | RISC |
| Number of UART Channels | 3 |
| Number of USART Channels | 3 |
| Program Memory Type | Flash |
| Pulse Width Modulation | 1 |
| ADC Resolution | 12bit |
| Minimum Operating Temperature | -40 °C |
