TDK-Lambda CCG15-48-xxD 15.6W Isolated DC-DC Converter PCB Mount, Voltage in 18 → 76 V dc, Voltage out ±12V dc [CCG15-48-12D]; 181-3292
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Output Voltage | ±12V dc |
| Input Voltage Range | 18 → 76 V dc |
| Input Voltage Nominal | 48 V dc |
| Isolation Voltage | 1.5kV dc |
| Power Rating | 15.6W |
| Output Current | 650mA |
| Mounting Type | PCB Mount |
| Number of Outputs | 2 |
| Efficiency | 0.89 |
| Package | 1 x 1 in |
| Load Regulation | 120mV |
| Minimum Temperature | -40°C |
| Maximum Temperature | +85°C |
| Length | 25.4mm |
| Width | 25.4mm |
| Standards Met | CSA60950-1, CSA62368-1, EN60950-1, EN62368-1, UL60950-1, UL62368-1 |
| Series | CCG15-48-xxD |
| Depth | 9.9mm |
