TE Connectivity PIDG Series Insulated Crimp Ring Terminal, M5 Stud Size, 1.65mm² to 3.45mm² Wire Size, Red, White [152872]; 164-1831
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Series | PIDG |
| Insulation | Insulated |
| Insulation Material | Nylon |
| Inner Ring Diameter | 5mm |
| Outer Ring Diameter | 8.71mm |
| Maximum Wire Size mm² | 3.45mm² |
| Minimum Wire Size mm² | 1.65mm² |
| Maximum Wire Size AWG | 12AWG |
| Minimum Wire Size AWG | 14AWG |
| Stud Size | M5 |
| Colour | Red, White |
| Contact Material | Copper |
| Contact Plating | Tin |
| Thickness | 0.75mm |
| Overall Length | 22mm |
