Black Button Tactile Switch, Single Pole Single Throw (SPST) 50 mA 3.4mm Through Hole [FSM103]; 875-0618
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Contact Configuration | Single Pole Single Throw (SPST) |
| Terminal Type | Pc Pin |
| Switch Operation | Momentary |
| Actuator Length | 3.4mm |
| Actuator Colour | Black |
| Actuator Type | Button |
| Length | 12mm |
| Width | 12mm |
| Dimensions | 12 x 12 x 7.28mm |
| Mounting Type | Through Hole |
| Contact Current Rating | 50 mA |
| Operating Force | 160 g |
| Maximum Operating Temperature | +85°C |
| Mechanical Life | 100000Cycles |
| Minimum Operating Temperature | -35°C |
| Contact Material | Brass (Fixed Contact), Phosphor Bronze (Movable) |
| Operating Temperature Range | -35 → +85°C |
| Voltage Rating | 24V dc |
| Height | 7.28mm |
