Tektronix TDS2012C Digital Oscilloscope, 2 Channels, 100MHz [TDS2012C]; 744-2470
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Number of Channels | 2 |
| Bandwidth | 100MHz |
| Oscilloscope Type | Digital Storage |
| Series | TDS2000C |
| Power Source | Mains |
| Display Type | Colour |
| Minimum Vertical Sensitivity | 2mV/div |
| Maximum Vertical Sensitivity | 5V/div |
| Minimum Time Base | 2.5ns/div |
| Maximum Time Base | 50s/div |
| Screen Size | 5.7in |
| Sample Rate Random | 2 Gsps |
| Plug Type | Type C - European Plug, Type G - British 3-pin, Type J - Swiss 3-pin |
| Safety Category Voltage | 300V |
| Length | 326.3mm |
| Safety Category | CAT II 300 V |
| Rise Time | 3.5ns |
| Maximum Operating Temperature | +50°C |
| USB Interface | Yes |
| Vertical Resolution | 8 bit |
| Model Number p | TDS2012C |
| Height | 158mm |
| Weight | 2kg |
| Width | 124.2mm |
| Record Length | 2.5k points/ch |
| Safety Category Level | CAT II |
| Dimensions | 326.3 x 124.2 x 158mm |
| Minimum Operating Temperature | 0°C |
