IP66 Snap Action Limit Switch Plunger Zinc Alloy, NO/NC, 240V [XCKL110]; 609-6546
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Actuator Type | Plunger |
| Pole and Throw Configuration | SPDT |
| Normal State Configuration | NO/NC |
| IP Rating | IP66 |
| Maximum Current | 0.416666666666667 |
| Housing Material | Zinc Alloy |
| Maximum AC Voltage | 240V |
| Maximum DC Voltage | 250V |
| Series | OsiSense XC |
| Contact Type | Snap Action |
| Terminal Type | Screw |
| Length | 72mm |
| Width | 52mm |
| Minimum Operating Temperature | -25°C |
| Mechanical Life Minimum | 20000000 cycles |
| Dimensions | 72 x 52 x 30 mm |
| Depth | 30mm |
| Maximum Operating Temperature | +70°C |
