CSD87350Q5D Dual N-Channel MOSFET Module, 120 A, 30 V NexFET, 8-Pin SON Texas Instruments [CSD87350Q5D]; 162-8561
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Channel Type | N |
| Maximum Continuous Drain Current | 120 A |
| Maximum Drain Source Voltage | 30 V |
| Package Type | SON |
| Mounting Type | Surface Mount |
| Pin Count | 8 |
| Maximum Drain Source Resistance | 1.2 mΩ, 5 mΩ |
| Channel Mode | Enhancement |
| Maximum Gate Threshold Voltage | 2.1V |
| Minimum Gate Threshold Voltage | 1V |
| Maximum Power Dissipation | 12 W |
| Transistor Configuration | Series |
| Maximum Gate Source Voltage | +8 V |
| Number of Elements per Chip | 2 |
| Typical Gate Charge @ Vgs | 8.4 nC @ 4.5 V, 20 nC @ 4.5 V |
| Length | 6.1mm |
| Transistor Material | Si |
| Minimum Operating Temperature | -55 °C |
| Series | NexFET |
| Width | 5.1mm |
| Height | 1.5mm |
| Maximum Operating Temperature | +150 °C |
