Texas Instruments UCC27714D Dual Full/Half Bridge Half Bridge MOSFET Power Driver, 4A, 10 → 18 V 14-Pin, SOIC [UCC27714D]; 133-0784
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Number of Drivers | 2 |
| Minimum Operating Supply Voltage | 10 V |
| Maximum Operating Supply Voltage | 18 V |
| Topology | Half Bridge |
| Mounting Type | Surface Mount |
| Peak Output Current | 4A |
| Number of Outputs | 2 |
| Polarity | Non-Inverting |
| Package Type | SOIC |
| Pin Count | 14 |
| Bridge Type | Full Bridge, Half Bridge |
| Input Logic Compatibility | CMOS, TTL |
| High and Low Sides Dependency | Independent |
| Width | 4mm |
| Height | 1.5mm |
| Dimensions | 8.75 x 4 x 1.5mm |
| Minimum Operating Temperature | -40 °C |
| Length | 8.75mm |
| Time Delay | 125ns |
| Maximum Operating Temperature | +125 °C |
| Rise Time | 30ns |
| Fall Time | 30ns |
