Toshiba 2SC5200-O(S1,F,S) NPN Transistor, 15 A, 230 V, 3-Pin TO-3PL [2SC5200-O(S1,F,S)]; 890-2682
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Transistor Type | NPN |
| Maximum DC Collector Current | 15 A |
| Maximum Collector Emitter Voltage | 230 V |
| Package Type | TO-3PL |
| Mounting Type | Through Hole |
| Maximum Power Dissipation | 150 W |
| Minimum DC Current Gain | 35 |
| Transistor Configuration | Single |
| Maximum Collector Base Voltage | 230 V |
| Maximum Emitter Base Voltage | 5 V |
| Pin Count | 3 |
| Number of Elements per Chip | 1 |
| Maximum Collector Emitter Saturation Voltage | 3 V |
| Length | 20.5mm |
| Maximum Operating Temperature | +150 °C |
| Width | 26mm |
| Height | 5.2mm |
| Transistor Material | Si |
| Dimensions | 20.5 x 26 x 5.2mm |
