Toshiba TC74AC02F(F), Quad 2-Input NOR Logic Gate, 2 → 5.5 V, 14-Pin SOP [TC74AC02F(F)]; 541-9724
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Logic Function | NOR |
| Mounting Type | Surface Mount |
| Number of Elements | 4 |
| Number of Inputs per Gate | 2 |
| Schmitt Trigger Input | No |
| Package Type | SOP |
| Pin Count | 14 |
| Logic Family | AC |
| Maximum Operating Supply Voltage | 5.5 V |
| Maximum High Level Output Current | -24mA |
| Maximum Propagation Delay Time @ Maximum CL | 7 ns @ 5 V, 9.8 ns @ 3.3 V |
| Minimum Operating Supply Voltage | 2 V |
| Maximum Low Level Output Current | 24mA |
| Propagation Delay Test Condition | 50pF |
| Dimensions | 10.3 x 5.3 x 1.5mm |
| Height | 1.5mm |
| Minimum Operating Temperature | -40 °C |
| Width | 5.3mm |
| Length | 10.3mm |
| Maximum Operating Temperature | +85 °C |
