Toshiba TC74HC123AF(F) Dual Monostable Multivibrator 5.2mA, 2 → 6 V, 16-Pin SOP [TC74HC123AF(F)]; 540-7692
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Logic Family | HC |
| Logic Function | Monostable Multivibrator |
| Number of Elements per Chip | 2 |
| Maximum High Level Output Current | -5.2mA |
| Maximum Low Level Output Current | 5.2mA |
| Minimum Pulse Width | 13 ns |
| Maximum Propagation Delay Time @ Maximum CL | 210 ns @ 2 V |
| Maximum Quiescent Current | 0.004mA |
| Mounting Type | Surface Mount |
| Package Type | SOP |
| Pin Count | 16 |
| Dimensions | 10.3 x 5.3 x 1.5mm |
| Height | 1.5mm |
| Length | 10.3mm |
| Maximum Operating Temperature | +85 °C |
| Minimum Operating Temperature | -40 °C |
| Width | 5.3mm |
| Minimum Operating Supply Voltage | 2 V |
| Maximum Operating Supply Voltage | 6 V |
