Toshiba TC74LCX00F(K,F), Quad 2-Input NAND Logic Gate, 2 → 3.6 V, 14-Pin SOP [TC74LCX00F(K,F)]; 756-2996
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Logic Function | NAND |
| Mounting Type | Surface Mount |
| Number of Elements | 4 |
| Number of Inputs per Gate | 2 |
| Schmitt Trigger Input | No |
| Package Type | SOP |
| Pin Count | 14 |
| Logic Family | LCX |
| Input Type | CMOS |
| Maximum Operating Supply Voltage | 3.6 V |
| Maximum High Level Output Current | +50mA |
| Maximum Propagation Delay Time @ Maximum CL | 6ns |
| Minimum Operating Supply Voltage | 2 V |
| Maximum Low Level Output Current | -50mA |
| Dimensions | 10.8 x 5.3 x 1.5mm |
| Propagation Delay Test Condition | 50pF |
| Length | 10.8mm |
| Maximum Operating Temperature | +85 °C |
| Height | 1.5mm |
| Width | 5.3mm |
| Output Type | CMOS |
| Minimum Operating Temperature | -40 °C |
