TRACOPOWER TEL 8WI 8W Isolated DC-DC Converter Through Hole, Voltage in 18 → 75 V dc, Voltage out 3.3V dc [TEL 8-4810WI]; 161-6765
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Output Voltage | 3.3V dc |
| Output Voltage Adjustment Range | ±2% |
| Input Voltage Range | 18 → 75 V dc |
| Input Voltage Nominal | 48 V dc |
| Isolation Voltage | 1.5kV dc |
| Power Rating | 8W |
| Output Current | 1.6A |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Efficiency | 0.78 |
| Package | DIP 16 |
| Load Regulation | 0.01 |
| Minimum Temperature | -40°C |
| Maximum Temperature | +80°C |
| Series | TEL 8WI |
| Standards Met | CUS Recognised, EN 55022 Class A, EN 55022 Class B, EN 55024, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, IEN 61000-4-2 |
| Length | 24.1mm |
| Width | 14mm |
| Depth | 8.5mm |
