TRACOPOWER THM 15WI 15W Isolated DC-DC Converter Through Hole, Voltage in 18 → 75 V dc, Voltage out ±5V dc [THM 15-4821WI]; 146-6098
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Output Voltage | ±5V dc |
| Input Voltage Range | 18 → 75 V dc |
| Input Voltage Nominal | 48 V dc |
| Isolation Voltage | 5kV ac |
| Power Rating | 15W |
| Output Current | ±1.5A |
| Mounting Type | Through Hole |
| Number of Outputs | 2 |
| Medical Approved | Yes |
| Package | 1.6 x 1 in |
| Minimum Temperature | -40°C |
| Load Regulation | 0.01 |
| Maximum Temperature | +85°C |
| Series | THM 15WI |
| Standards Met | ANSI/AAMI ES 60601-1, CB, EMC, EN 55011, EN 55032, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, ES 60601-1, IEC 60601-1, IEC 60601-1-2, IEC/EN 60601-1-2, MIL-STD-810F |
| Width | 25.4mm |
| Depth | 10.2mm |
| Length | 40.6mm |
